Shelly Wave Plug LR UK – Z-Wave Long Range Smart Plug with Power Monitoring (13A)
Overview
Shelly Wave Plug LR UK is a Z-Wave Long Range (ZWLR) smart plug with integrated power monitoring, designed for controlling and measuring mains-powered appliances up to 3000 W at 13 A. It supports both standard Z-Wave mesh and Z-Wave Long Range connections, depending on the hub and network configuration.
Key Features
• Controls resistive loads up to 3000 W (13 A)
• Power consumption monitoring per connected appliance
• Z-Wave Long Range (ZWLR) direct-to-hub support
• Standard Z-Wave mesh repeater support (non-LR mode)
• LED ring indicates power usage and device status
• Overcurrent, overheating, and overvoltage protection
• SmartStart for automatic Z-Wave provisioning
• OTA firmware updates
• Security 2 Authenticated (S2)
Technical Specifications
Electrical
Power Supply: 230 V AC ±10%, 50/60 Hz
Max Load: 3000 W (resistive)
Max Current: 13 A
Standby Power Consumption: < 0.7 W
Power Monitoring: Yes
Z-Wave
Protocols: Z-Wave Plus, Z-Wave Long Range (ZWLR)
Frequency Bands:
• 868.4 MHz (Z-Wave Plus)
• 864.0 MHz (ZWLR)
Chipset: Z-Wave S800
Security: S2 Authenticated
Repeater Function:
• Yes (Z-Wave mesh)
• No (ZWLR mode)
Wireless Range (typical)
Z-Wave Mesh: Up to 40 m indoors
Z-Wave Long Range: Up to 80 m indoors, up to 1000 m outdoors
Physical
Dimensions: 60 × 60 × 56 mm
Weight: 74 g
Socket Type: BS 1363 (UK Type G)
Material: Plastic
Colour: White
Environmental
Operating Temperature: -20 °C to 40 °C
Humidity: 30–70% RH
Max Altitude: 2000 m
Installation Notes
• Requires a compatible Z-Wave hub (not included)
• Z-Wave Long Range requires an LR-capable receiver (e.g. Home Assistant ZWA-2)
• In ZWLR mode, the device connects directly to the hub and does not act as a repeater
• In standard Z-Wave mode, the plug participates in the mesh and acts as a repeater
• LED ring behaviour can be configured or disabled
• Indoor use only
• Also available in a Wi-Fi (non Z-Wave) version
In the Box
• Shelly Wave Plug LR UK
• Quick start guide
