Shelly Pro Dual Cover / Shutter PM
£104.99
1 in stock
Overview
Shelly Pro Dual Cover / Shutter PM is a professional DIN-rail smart controller for dual covers or shutters with integrated power metering. Designed for roller shutters, awnings, gates, curtains, garage doors, and other bi-directional AC motors, it provides precise position control and real-time energy monitoring per cover. With LAN, Wi-Fi, and Bluetooth connectivity, single-phase operation, and free data storage, it is ideal for professional, commercial, and advanced residential installations requiring reliable cover automation from a breaker box.
Key features
- Professional DIN-rail dual cover and shutter controller
- Controls two independent covers or shutters
- Integrated power metering on each cover with free data storage
- Supports roller shutters, awnings, gates, curtains, garage doors, and bi-directional AC motors
- Single-phase control with precise position management
- LAN, Wi-Fi, and Bluetooth connectivity
- Designed for installation in electrical cabinets
- Supports schedules, scripting, webhooks, and automation platforms
- Compatible with voice assistants and smart home systems
Product information
Use cases
- Dual Shutter and Blind Automation
- Automate and precisely control two roller shutters, blinds, or awnings with position feedback.
- Motorised Gate and Door Control
- Control gates, barriers, sliding doors, or garage doors using bi-directional AC motors.
- Energy Monitoring for Covers
- Measure voltage, current, and power consumption for each motor to optimise usage and detect issues.
- Professional Installations
- Deploy in commercial or advanced residential setups requiring centralised DIN-rail control and monitoring.
Technical specifications
Physical
Size (HxWxD)
96 × 53 × 59 mm
Weight
0.150 kg
Mounting
DIN rail
Shell material
Plastic
Colour
Black
Environmental
Ambient temperature
-20°C to +40°C
Humidity
30% to 70% RH
Max altitude
2000 m
Electrical
Power supply AC
110–240 V
Power supply DC
N/A
Power consumption
< 3 W
Neutral required
Yes
Output Circuit Ratings
Controlled motor max power
1.0 HP @ 240 VAC, 0.5 HP @ 120 VAC
Sensors and Meters
Voltmeter (AC)
Yes
Ammeter (AC)
Yes
Temperature sensor
Yes
Radio
RF band
2400–2495 MHz
Max RF power
< 20 dBm
Wi-Fi protocol
802.11 b/g/n
Wi-Fi range
Up to 30 m indoors / 50 m outdoors (depending on conditions)
Bluetooth protocol
4.2
Bluetooth range
Up to 10 m indoors / 30 m outdoors
MCU
CPU
ESP32-D0WDQ6
Flash
8 MB
Firmware Capabilities
Schedules
20
Webhooks (URL actions)
20 (5 URLs per hook)
Scripting
mJS
MQTT
Yes
CoAP
No
What’s included
- Shelly Pro Dual Cover / Shutter PM DIN-rail controller
